| Model |
PWS5610S-S |
PWS5610T-S |
| LCD Type |
Mono STN LCD |
Color TFT LCD |
| Screen size |
5.7”(diagonal) |
| Display resolution |
320 x 240 |
| Brightness (cd/m2) |
110 |
400 |
|
|
|
| Contrast adjustment |
Via touch panel |
— |
|
16 shades of blue |
|
| Display colors |
|
256 colors |
| Back light type |
LED |
| CPU |
32-bit RISC |
| Back light life |
20,000 hours |
50,000 hours |
| Operation Status LED |
PWR & COM1, COM2 LEDs |
|
|
| Touch screen |
Analog |
|
|
| Touch screen |
|
| (number of times) |
> 1,000,000 |
|
|
|
|
| Keypad |
— |
| Application Flash ROM |
2MB |
| RAM |
512KB |
| Data/Recipe |
256KB |
| RTC |
|
| (w/rechargeable lithium battery) |
changeable lithium battery |
|
|
| Data storage (CF card) |
— |
|
9-pin female(RS232/RS485/ RS422 without RTS/CTS) or (RS232,COM2 RS422/RS485 |
| COM1 |
without RTS/CTS) |
|
|
| COM2 |
— |
|
|
| COM3 |
— |
| USB Host |
— |
| USB Device |
— |
|
|
| Multi-functional port |
— |
|
|
| Ethernet |
— |
|
|
| External dimensions (mm) |
195.0 (W) x 145.0 (H) x 40.2 (D) |
| Cut-out dimensions (mm) |
185.8 x 135.8 |
| Supply voltage |
24V DC ±15 %, < 8W |
| Front protection |
IP65 |
| Certification |
CE,FCC |
| Weight (kg) |
0.55 |
0.5 |
