9 inch Siemens SIMATIC HMI KTP900F Mobile Panel Touch Screen 6AV2125-2JB23-0AX0

Qty:

Add to Enquiry Cart

Specification

Download A Munual

General information	9 inch Siemens SIMATIC HMI KTP900F Mobile Panel Touch Screen 6AV2125-2JB23-0AX0
Product type designation	KTP900F Mobile
Design of display	TFT widescreen display, LED backlighting
Screen diagonal	9 in
Color display	Yes
Number of colors	16 777 216
● Horizontal image resolution ● Vertical image resolution	800 Pixel 480 Pixel
● MTBF backlighting (at 25 °C) ● Backlight dimmable	50 000 h Yes; 0-100 %
— Number of function keys	10
— Number of function keys with LEDs	10
● Keys with LED ● Numeric keyboard ● alphanumeric keyboard	Yes Yes; Yes;	Onscreen Onscreen	keyboard keyboard
● Design as touch screen ● Design as multi-touch screen	Yes No
● Stop button (forced blocking)	Yes
● Emergency stop button (illuminated and forced blocking)	Yes
● Acknowledgement button (3-stage)	Yes
● Key-operated switch	Yes
● Illuminated pushbutton	Yes
● integrated camera	No
● DP direct LEDs (LEDs as S7 output I/O)
— F1…Fx	10
● Direct keys (keys as S7 input I/O)
— F1…Fx	10
● Direct keys (touch buttons as S7 input I/O)	32
Type of supply voltage	DC
Rated value (DC)	24 V
permissible range, lower limit (DC)	19.2 V
permissible range, upper limit (DC)	28.8 V
Current consumption (rated value)	450 mA
Starting current inrush I²t	0.135 A²·s
Active power input, typ.	11 W
Processor type	ARM
Flash	Yes
RAM	Yes
Memory available for user data	12 Mbyte
