| Mitsubishi VFDs Inverter | FR-D720S 0.75kW to 2.2kw | |||||
| Model FR-D720S-oK | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 |
| Model FR-D720S-o-NA | 008 | 014 | 025 | 042 | 070 | 100 |
| Model FR-D720S-o-EC | 008 | 014 | 025 | 042 | 070 | 100 |
| Model FR-D720S-oK-CHT | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 |
| Applicable motor capacity (kW)*1 | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 |
| Rated capacity (kVA)*2 | 0.3 | 0.6 | 1.0 | 1.7 | 2.8 | 4.0 |
| Rated current (A) | 0.8 | 1.4 | 2.5 | 4.2 | 7.0 | 10.0 |
| Overload current rating*3 | 150% 60s, 200% 0.5s (inverse-time characteristics) | |||||
| Voltage*4 | Three-phase 200 to 240V | |||||
| Regenerative braking torque*5 | 150% | 100% | 50% | 20% | ||
| Power supply
Rated input AC voltage/frequency |
Single-phase 200 to 240V 50Hz/60Hz | |||||
| Permissible AC voltage fluctuation | 170 to 264V 50Hz/60Hz | |||||
| Permissible frequency fluctuation | ±5% | |||||
| Power supply capacity (kVA)*6 | 0.5 | 0.9 | 1.5 | 2.3 | 4.0 | 5.2 |
| Protective structure (JEM1030) | Enclosed type (IP20). | |||||
| Cooling system | Self-cooling | Forced air cooling | ||||
| Approximate mass (kg) | 0.5 | 0.5 | 0.9 | 1.1 | 1.5 | 2.0 |
