Omron Photomicro sensor EE-SPZ301-A EE-SPZ401-A

Omron Retroreflective Photomicrosensor with Lens EE-SPZ-A
We are First Class Omron sensor dealer and Omron sensor distributor in China.
We can Supply all kinds of Omron sensor parts,such as Omron Photomicro Sensors,Omron Proximity Sensors,Omron Fiber Sensors,Omron Photoelectric Sensors and Omron Rotary Encoder.
All parts are 100% Original and new in stock by Omron and fast delivery time within 1 day
100% after sale service and technology Support
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Models	EE-SPZ301-A, EE-SPZ401-A
*Sensing distance 1**	200 mm ( using E39-R1 reflector)
Light source	GaAs infrared LED (pulse lighting) with a peak wavelength of 940 nm
*Indicator 2**	Light indicator (red)
Supply voltage	5 to 24 VDC ±10%, ripple (p-p): 5% max.
Current consumption	Average: 15 mA max., Peak: 50 mA max.
Control output	NPN voltage output Load power supply voltage: 5 to 24 VDC Load current: 80 mA max. OFF current: 0.5 mA max. 80 mA load current with a residual voltage of 1.0 V max. 10 mA load current with a residual voltage of 0.4 V max.
*Response frequency 3**	100 Hz min.
Ambient illumination	3,000 lx max. with incandescent light or sunlight on the surface of the receiver
Ambient temperature range	Operating: – 10 to +55 ° C Storage: – 25 to +65 ° C
Ambient humidity range	Operating: 5% to 85% Storage: 5% to 95%
Vibration resistance	Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 h each in X, Y, and Z directions
Shock resistance	Destruction: 500 m/s² for 3 times each in X, Y, and Z directions
Degree of protection	IEC IP50
Connecting method	Special connector (soldering not possible)
Weight (packaged)	Approx. 3 g
