| GP2300-LG41-24V GP2301-LG41-24V | GP2300-SC41-24V GP2301-SC41-24V | GP2300-TC41-24V GP2301-TC41-24V | |
| Type | Monochrome LCD | STN type color LCD | TFT type color LCD |
| Resolution | 320 x 240pixels | ||
| Effective Display Area | W115.2mm [4.54in.] x H86.4mm [3.40in.] | ||
|
Colors |
Black and White, 2 levels of gray/ Black and White, 8 levels of gray*1
(Color switching is done via software) |
64 colors/3-speed blink |
256/No blink*2, 64 colors/3-speed blink (Color switching is done via software) |
| Backlight | CCFL (Service life: 50,000 hrs. at 25oC and 24hr. operation) | ||
| Contrast Adjustment | 8 levels of adjustment available via touch panel. | ||
| Brightness
Adjustment |
4 levels of adjustment available via touch panel. | ||
|
Language Fonts |
ASCII: (Code page 850) Alphanumeric (incl. Eur. characters) Chinese: (GB2312-80 codes) simplified Chinese fonts Japanese: ANK 158, Kanji : 6,962 (JIS Standards 1 & 2)
(including 607 non-kanji characters) Korean: (KSC5601 – 1992 codes) Hangul fonts Taiwanese: (Big 5 codes) traditional Chinese fonts |
||
| Character Sizes *3 | 8X8, 8X16, 16X16 and 32X32 dot fonts | ||
|
Font Sizes |
Width can be expanded 1 to 8 times.
Height can be expanded 1/2*4, 1 to 8 times. |
||
