| Article number | 6ES7134-4FB01-0AB0 | 6ES7134-4LB02-0AB0 | 6ES7134-4GB01-0AB0 | 6ES7134-4GB52-0AB0 |
| ET200S, El-Mod., 2AI Std U, +/-10V,1-5V | ET200S, El-Mod., 2AI U HF, +/-10V, 1..5V | ET200S, El-Mod., 2AI Std I-2DMU, 0-20mA, | ET200S, El-Mod., 2AI HS I-2DMU, 0-20mA, | |
| Supply voltage | ||||
| Load voltage L+ | ||||
|
● Rated value (DC)
|
24 V; From power module | 24 V | 24 V; From power module | 24 V |
|
● Short-circuit protection
|
Yes | |||
|
● Reverse polarity protection
|
Yes | Yes | Yes; Destruction limit 35 mA per channel | Yes |
| Input current | ||||
| from load voltage L+ (without load), max. | 30 mA | 55 mA | 80 mA | 225 mA |
| from backplane bus 3.3 V DC, max. | 10 mA | 10 mA | 10 mA | 10 mA |
| Output voltage | ||||
| Power supply to the transmitters | ||||
|
● present
|
No | Yes | ||
| Power loss | ||||
| Power loss, typ. | 0.6 W | 0.85 W | 0.6 W | 2.5 W |
| Address area | ||||
| Address space per module | ||||
|
● Address space per module, max.
|
4 byte | 4 byte | 4 byte | 4 byte |
| Analog inputs | ||||
| Number of analog inputs | 2 | 2 | 2 | 2 |
| permissible input voltage for voltage input (destruction limit), max. | 35 V; 35 V continuous; 75 V for max. 1 ms (mark to space ratio 1:20) | 35 V; 35 V continuous; 75 V for max. 1 ms | ||
| permissible input current for current input (destruction limit), max. | 40 mA | |||
| Cycle time (all channels) max. | Number of active channels per module x basic conversion time | 0.5 ms; 0.5 ms for 2 channels without noise suppression, 18 / 21 ms per channel with noise suppression | Number of active channels per module x basic conversion time | 0.25 ms |
| Input ranges (rated values), voltages | ||||
|
● 1 V to 5 V
|
Yes | Yes | ||
|
— Input resistance (1 V to 5 V)
|
800 kΩ | |||
|
● -10 V to +10 V
|
Yes | Yes | ||
|
— Input resistance (-10 V to +10 V)
|
800 kΩ | |||
|
● -5 V to +5 V
|
Yes | Yes | ||
|
— Input resistance (-5 V to +5 V)
|
800 kΩ | |||
| Input ranges (rated values), currents | ||||
|
● 0 to 20 mA
|
Yes | |||
|
— Input resistance (0 to 20 mA)
|
106 Ω | |||
|
● 4 mA to 20 mA
|
Yes; on 50 ohms | Yes | ||
| Cable length | ||||
|
● shielded, max.
|
200 m | 200 m | 200 m | 200 m |
| Analog value generation for the inputs | ||||
| Integration and conversion time/resolution per channel | ||||
|
● Resolution with overrange (bit including sign), max.
|
14 bit; ±10 V: 13 bit + sign, ±5 V: 13 bit + sign; 1 to 5 V: 13 bit | 16 bit; 0 to 5 V: 15 bit, ±10 V: 16 bit, ±5 V: 16 bit | 13 bit; 4 to 20 mA: 13 bit | 16 bit |
|
● Integration time, parameterizable
|
Yes | Yes | ||
|
● Integration time (ms)
|
16,7 / 20 ms | 16,7 / 20 ms | ||
|
● Interference voltage suppression for interference frequency f1 in Hz
|
50 / 60 Hz | 60 / 50 Hz / no | 50 / 60 Hz | |
|
● Conversion time (per channel)
|
65 ms; 55 / 65 ms | 0.04 ms; Without noise suppression 17/20 ms per channel with error | 65 ms; 55 / 65 ms | |
| Encoder | ||||
| Connection of signal encoders | ||||
|
● for voltage measurement
|
Yes | |||
|
● for current measurement as 2-wire transducer
|
Yes | |||
| Errors/accuracies | ||||
| Operational error limit in overall temperature range | ||||
|
● Voltage, relative to input range, (+/-)
|
0.6 % | 0.1 %; 0.2% without interference frequency suppression | ||
|
● Current, relative to input range, (+/-)
|
0.6 % | 0.3 % | ||
| Basic error limit (operational limit at 25 °C) | ||||
|
● Voltage, relative to input range, (+/-)
|
0.4 % | 0.05 %; 0.1% without interference frequency suppression | ||
|
● Current, relative to input range, (+/-)
|
0.4 % | 0.2 % | ||
| Interrupts/diagnostics/status information | ||||
| Alarms | ||||
|
● Hardware interrupt
|
Yes | Yes | ||
| Diagnoses | ||||
|
● Wire-break
|
Yes; Measuring range 1 to 5 V only | Yes; Measuring range 1 to 5 V only | Yes | Yes; at 4 to 20 mA |
|
● Group error
|
Yes | Yes | Yes | Yes |
|
● Overflow/underflow
|
Yes | Yes | Yes | Yes |
| Diagnostics indication LED | ||||
|
● Group error SF (red)
|
Yes | Yes | Yes | Yes |
| Parameter | ||||
| Remark | 4 byte | 12 bytes, 4 bytes in compatibility mode | 4 byte | |
| Diagnostics wire break | Disable / enable (only in measuring range 1 to 5 V) | At 4 to 20 mA | ||
| Measurement type/range | deactivated / ±5 V / 1 to 5 V / ±10 V | deactivated / ±5 V / 1 to 5 V / ±10 V | deactivated / 4 to 20 mA | 4 to 20 mA, 0 to 20 mA |
| Group diagnostics | Disable / enable | Disable / enable | Disable / enable | 1 |
| Overflow/underflow | Disable / enable | Disable / enable | Disable / enable | 1 |
| Potential separation | ||||
| Potential separation analog inputs | ||||
|
● between the channels
|
No | No; however, increased permissible potential difference between the inputs. | No | No |
|
● between the channels and backplane bus
|
Yes | Yes | Yes | Yes |
|
● Between the channels and load voltage L+
|
Yes | Yes | No | Yes |
| Isolation | ||||
| Isolation tested with | 500 V DC | 500 V DC | 500 V DC | |
| Dimensions | ||||
| Width | 15 mm | 15 mm | 15 mm | 15 mm |
| Height | 81 mm | 81 mm | 81 mm | 81 mm |
| Depth | 52 mm | 52 mm | 52 mm | 52 mm |
| Weights | ||||
| Weight, approx. | 40 g | 45 g | 40 g |
