| Article number | 6ES7522-1BH10-0AA0 | 6ES7522-1BL10-0AA0 |
| S7-1500, DQ 16x24VDC/0.5A BA | S7-1500, DQ 32x24VDC/0.5A BA | |
| General information | ||
| Product type designation | DQ 16x24VDC/0.5A BA | DQ 32x24VDC/0.5A BA |
| HW functional status | FS01 | FS01 |
| Firmware version | V1.0.0 | V1.0.0 |
|
● FW update possible
|
Yes | Yes |
| Product function | ||
|
● I&M data
|
Yes; I&M0 to I&M3 | Yes; I&M0 to I&M3 |
|
● Isochronous mode
|
No | No |
|
● Prioritized startup
|
Yes | Yes |
| Engineering with | ||
|
● STEP 7 TIA Portal configurable/integrated from version
|
V13 / V13 | V13 / V13 |
|
● STEP 7 configurable/integrated from version
|
V5.5 SP3 / – | V5.5 SP3 / – |
|
● PROFIBUS from GSD version/GSD revision
|
V1.0 / V5.1 | V1.0 / V5.1 |
|
● PROFINET from GSD version/GSD revision
|
V2.3 / – | V2.3 / – |
| Operating mode | ||
|
● DQ
|
Yes | Yes |
|
● DQ with energy-saving function
|
No | No |
|
● PWM
|
No | No |
|
● Oversampling
|
No | No |
|
● MSO
|
Yes | Yes |
| Supply voltage | ||
| Rated value (DC) | 24 V | 24 V |
| permissible range, lower limit (DC) | 20.4 V | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V | 28.8 V |
| Reverse polarity protection | Yes; through internal protection with 7 A per group | Yes; through internal protection with 7 A per group |
| Input current | ||
| Current consumption, max. | 30 mA | 60 mA |
| Output voltage | ||
| Rated value (DC) | 24 V | 24 V |
| Power | ||
| Power available from the backplane bus | 1.15 W | 1.15 W |
| Power loss | ||
| Power loss, typ. | 2.2 W | 3.8 W |
| Digital outputs | ||
| Type of digital output | Transistor | Transistor |
| Number of digital outputs | 16 | 32 |
| Current-sourcing | Yes | Yes |
| Digital outputs, parameterizable | No | No |
| Short-circuit protection | Yes | Yes |
|
● Response threshold, typ.
|
1 A | 1 A |
| Limitation of inductive shutdown voltage to | L+ (-53 V) | L+ (-53 V) |
| Controlling a digital input | Yes | Yes |
| Switching capacity of the outputs | ||
|
● with resistive load, max.
|
0.5 A | 0.5 A |
|
● on lamp load, max.
|
5 W | 5 W |
| Load resistance range | ||
|
● lower limit
|
48 Ω | 48 Ω |
|
● upper limit
|
12 kΩ | 12 kΩ |
| Output voltage | ||
|
● for signal “1”, min.
|
L+ (-0.8 V) | L+ (-0.8 V) |
| Output current | ||
|
● for signal “1” rated value
|
0.5 A | 0.5 A |
|
● for signal “1” permissible range, max.
|
0.5 A | 0.5 A |
|
● for signal “0” residual current, max.
|
0.5 mA | 0.5 mA |
| Output delay with resistive load | ||
|
● “0” to “1”, max.
|
100 µs | 100 µs |
|
● “1” to “0”, max.
|
500 µs | 500 µs |
| Parallel switching of two outputs | ||
|
● for logic links
|
Yes | Yes |
|
● for uprating
|
No | No |
|
● for redundant control of a load
|
Yes | Yes |
| Switching frequency | ||
|
● with resistive load, max.
|
100 Hz | 100 Hz |
|
● with inductive load, max.
|
0.5 Hz; According to IEC 60947-5-1, DC-13 | 0.5 Hz; According to IEC 60947-5-1, DC-13 |
|
● on lamp load, max.
|
10 Hz | 10 Hz |
| Total current of the outputs | ||
|
● Current per channel, max.
|
0.5 A; see additional description in the manual | 0.5 A; see additional description in the manual |
|
● Current per group, max.
|
4 A; see additional description in the manual | 4 A; see additional description in the manual |
|
● Current per module, max.
|
8 A; see additional description in the manual | 16 A; see additional description in the manual |
| Cable length | ||
|
● shielded, max.
|
1 000 m | 1 000 m |
|
● unshielded, max.
|
600 m | 600 m |
| Interrupts/diagnostics/status information | ||
| Diagnostics function | No | No |
| Substitute values connectable | No | No |
| Alarms | ||
|
● Diagnostic alarm
|
No | No |
|
● Maintenance interrupt
|
No | No |
| Diagnoses | ||
|
● Monitoring the supply voltage
|
No | No |
|
● Wire-break
|
No | No |
|
● Short-circuit
|
No | No |
|
● Group error
|
No | No |
| Diagnostics indication LED | ||
|
● RUN LED
|
Yes; green LED | Yes; green LED |
|
● ERROR LED
|
Yes; red LED | Yes; red LED |
|
● Monitoring of the supply voltage (PWR-LED)
|
Yes; green LED | Yes; green LED |
|
● Channel status display
|
Yes; green LED | Yes; green LED |
|
● for channel diagnostics
|
No | No |
|
● for module diagnostics
|
No | No |
| Potential separation | ||
| Potential separation channels | ||
|
● between the channels
|
No | No |
|
● between the channels, in groups of
|
8 | 8 |
|
● between the channels and backplane bus
|
Yes | Yes |
| Isolation | ||
| Isolation tested with | 707 V DC (type test) | 707 V DC (type test) |
| Standards, approvals, certificates | ||
| Suitable for safety functions | No | No |
| Altitude during operation relating to sea level | ||
|
● Installation altitude above sea level, max.
|
5 000 m; Restrictions for installation altitudes > 2 000 m, see manual | 5 000 m; Restrictions for installation altitudes > 2 000 m, see manual |
| Dimensions | ||
| Width | 25 mm | 25 mm |
| Height | 147 mm | 147 mm |
| Depth | 129 mm | 129 mm |
| Weights | ||
| Weight, approx. | 230 g | 280 g |
