Siemens PLCs SIMATIC S7-300 Analog output SM 332 6ES7332-5HF00-0AB0

Siemens PLCs SIMATIC S7-300 Analog output SM 332 6ES7332-5HF00-0AB0

Series#: Siemens PLC

Product Details

Siemens PLCs SIMATIC S7-300 Analog output SM 332 6ES7332-5HF00-0AB0
Siemens PLC Controller Module LOGO Series
We are First Class Siemens Supplier,siemens plc dealer and Siemens plc distributor in China.
We can Supply Siemens automation parts,such as Siemens PLC,Siemens Servo Motor,Siemens HMI,Siemens VFD and So on,
100% Original and new,In stock by Siemens Automation
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Article number	6ES7332-5HB01-0AB0	6ES7332-5HD01-0AB0	6ES7332-5HF00-0AB0	6ES7332-7ND02-0AB0
	SM332, 2AA, U/I, 11/12Bit	SM332, 4AO, U/I, 11/12Bit	SM332, 8AA, U/I, 11/12Bit	SM332, 4AA, 0-10V, 0-5V,+/-10V,+/-20mA
Supply voltage
Load voltage L+
● Rated value (DC)	24 V	24 V	24 V	24 V
● Reverse polarity protection	Yes	Yes	Yes	Yes
Input current
from load voltage L+ (without load), max.	135 mA	240 mA	340 mA	290 mA
from backplane bus 5 V DC, max.	60 mA	60 mA	100 mA	120 mA
Power loss
Power loss, typ.	3 W	3 W	6 W	3 W
Analog outputs
Number of analog outputs	2	4	8	4; Isochronous mode
Voltage output, short-circuit protection	Yes	Yes	Yes	Yes
Voltage output, short-circuit current, max.	25 mA	25 mA	25 mA	40 mA
Current output, no-load voltage, max.	18 V	18 V	18 V	18 V
Output ranges, voltage
● 0 to 10 V	Yes	Yes	Yes	Yes
● 1 V to 5 V	Yes	Yes	Yes	Yes
● -10 V to +10 V	Yes	Yes	Yes	Yes
Output ranges, current
● 0 to 20 mA	Yes	Yes	Yes	Yes
● -20 mA to +20 mA	Yes	Yes	Yes	Yes
● 4 mA to 20 mA	Yes	Yes	Yes	Yes
Load impedance (in rated range of output)
● with voltage outputs, min.	1 kΩ	1 kΩ	1 kΩ	1 kΩ
● with voltage outputs, capacitive load, max.	1 µF	1 µF	1 µF	1 µF
● with current outputs, max.	500 Ω	500 Ω	500 Ω	500 Ω
● with current outputs, inductive load, max.	10 mH	10 mH	10 mH	1 mH
Cable length
● shielded, max.	200 m	200 m	200 m	200 m
Analog value generation for the outputs
Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), max.	12 bit; ±10 V, ±20 mA, 4 mA to 20 mA, 1 V to 5 V: 11 bit + sign; 0 V to 10 V, 0 mA to 20 mA: 12 bit	12 bit; ±10 V, ±20 mA, 4 mA to 20 mA, 1 V to 5 V: 11 bit + sign; 0 V to 10 V, 0 mA to 20 mA: 12 bit	12 bit; ±10 V, ±20 mA, 4 mA to 20 mA, 1 V to 5 V: 11 bit + sign; 0 V to 10 V, 0 mA to 20 mA: 12 bit	16 bit
● Conversion time (per channel)	0.8 ms	0.8 ms	0.8 ms	200 µs; in isochronous mode 640 µs
Settling time
