| Article number | 6ES7417-5HT06-0AB0 |
| Article number | CPU417-5H PN/DP, 32MB F. S7-400H/F/FH |
| General information | |
| Product type designation | CPU 417-5H PN/DP |
| HW functional status | 1 |
| Firmware version | V6.0 |
| Product function | |
|
● Isochronous mode
|
No |
| Engineering with | |
|
● Programming package
|
As of STEP 7 V5.5 SP2 with HF1 |
| CiR – Configuration in RUN | |
| CiR synchronization time, basic load | 60 ms |
| CiR synchronization time, time per I/O byte | 0 µs |
| Supply voltage | |
| Rated value (DC) | |
|
● 24 V DC
|
No; Power supply via system power supply |
| Input current | |
| from backplane bus 5 V DC, typ. | 1.6 A |
| from backplane bus 5 V DC, max. | 1.9 A |
| from backplane bus 24 V DC, max. | 150 mA; 150 mA per DP interface |
| from interface 5 V DC, max. | 90 mA; At each DP interface |
| Power loss | |
| Power loss, typ. | 7.5 W |
| Memory | |
| Type of memory | other |
| Work memory | |
|
● integrated
|
32 Mbyte |
|
● integrated (for program)
|
16 Mbyte |
|
● integrated (for data)
|
16 Mbyte |
|
● expandable
|
No |
| Load memory | |
|
● expandable FEPROM
|
Yes; with Memory Card (FLASH) |
|
● expandable FEPROM, max.
|
64 Mbyte |
|
● integrated RAM, max.
|
1 Mbyte |
|
● expandable RAM
|
Yes |
|
● expandable RAM, max.
|
64 Mbyte |
| Backup | |
|
● present
|
Yes |
|
● with battery
|
Yes; all data |
|
● without battery
|
No |
| Battery | |
| Backup battery | |
|
● Backup current, typ.
|
180 µA; Valid up to 40°C |
|
● Backup current, max.
|
1 000 µA |
|
● Backup time, max.
|
Dealt with in the module data manual with the secondary conditions and the factors of influence |
|
● Feeding of external backup voltage to CPU
|
5 V DC to 15 V DC |
| CPU processing times | |
| for bit operations, typ. | 7.5 ns |
| for word operations, typ. | 7.5 ns |
| for fixed point arithmetic, typ. | 7.5 ns |
| for floating point arithmetic, typ. | 15 ns |
