| Article number | 6ES7523-1BL00-0AA0 | 6ES7523-1BP50-0AA0 |
| S7-1500, DI 16x24VDC/DQ 16x24VDC/0.5A BA | S7-1500, DI 32x24VDC/DQ 32x24VDC/0.3A BA | |
| General information | ||
| Product type designation | DI 16x24VDC / DQ16x24VDC/0.5A BA | DI 32 x 24 V DC / DQ 32 x 24 V DC/0.3A SNK BA |
| HW functional status | FS01 | From FS01 |
| Firmware version | V1.0.0 | V1.0.0 |
|
● FW update possible
|
Yes | Yes |
| Product function | ||
|
● I&M data
|
Yes; I&M0 to I&M3 | Yes; I&M0 to I&M3 |
|
● Isochronous mode
|
No | No |
|
● Prioritized startup
|
Yes | No |
| Engineering with | ||
|
● STEP 7 TIA Portal configurable/integrated from version
|
V13 / V13 | V16 with HSP 0319 / V17 |
|
● STEP 7 configurable/integrated from version
|
V5.5 SP3 / – | V5.5 SP3 / – |
|
● PROFIBUS from GSD version/GSD revision
|
V1.0 / V5.1 | V1.0 / V5.1 |
|
● PROFINET from GSD version/GSD revision
|
V2.3 / – | V2.35 / – |
| Operating mode | ||
|
● DI
|
Yes | Yes |
|
● Counter
|
No | No |
|
● DQ
|
Yes | Yes |
|
● DQ with energy-saving function
|
No | No |
|
● PWM
|
No | No |
|
● Cam control (switching at comparison values)
|
No | |
|
● Oversampling
|
No | No |
|
● MSI
|
Yes | Yes |
|
● MSO
|
Yes | Yes |
|
● Integrated operating cycle counter
|
No | |
| Supply voltage | ||
| Rated value (DC) | 24 V | 24 V |
| permissible range, lower limit (DC) | 20.4 V | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V | 28.8 V |
| Reverse polarity protection | Yes; through internal protection with 7 A per group | Yes; Through internal protection with 4 A per group |
| external protection for power supply lines (recommendation) | input side: 24 V DC/4 A miniature circuit breaker with type B or C tripping characteristic; output side: 24 V DC/6 A miniature circuit breaker with type B tripping characteristic | |
| Input current | ||
| Current consumption, max. | 30 mA | 45 mA; without load |
| Output voltage | ||
| Rated value (DC) | 24 V | 24 V |
| Power | ||
| Power available from the backplane bus | 1.1 W | 0.6 W |
| Power loss | ||
| Power loss, typ. | 3.45 W | 4.7 W |
| Digital inputs | ||
| Number of digital inputs | 16 | 32 |
| Digital inputs, parameterizable | No | No |
| Source/sink input | P-reading | Yes |
| Input characteristic curve in accordance with IEC 61131, type 3 | Yes | Yes |
| Number of simultaneously controllable inputs | ||
|
● Number of simultaneously controllable inputs
|
32 | |
| horizontal installation | ||
|
— up to 60 °C, max.
|
32 | |
| vertical installation | ||
|
— up to 40 °C, max.
|
16 | |
| Input voltage | ||
|
● Rated value (DC)
|
24 V | 24 V |
|
● for signal “0”
|
-30 to +5 V | -30 to +5 V |
|
● for signal “1”
|
+11 to +30V | +11 to +30V |
| Input current | ||
|
● for signal “1”, typ.
|
2.7 mA | 2.7 mA |
| Input delay (for rated value of input voltage) | ||
| for standard inputs | ||
|
— parameterizable
|
No | No |
|
— at “0” to “1”, min.
|
3 ms | 3 ms |
|
— at “0” to “1”, max.
|
4 ms | 4 ms |
|
— at “1” to “0”, min.
|
3 ms | 3 ms |
|
— at “1” to “0”, max.
|
4 ms | 4 ms |
| for interrupt inputs | ||
|
— parameterizable
|
No | No |
| for technological functions | ||
|
— parameterizable
|
No | |
| Cable length | ||
|
● shielded, max.
|
1 000 m | 1 000 m |
|
● unshielded, max.
|
600 m | 600 m |
| Digital outputs | ||
| Type of digital output | Transistor | Transistor |
| Number of digital outputs | 16 | 32 |
| Current-sinking | Yes | |
| Current-sourcing | Yes | No |
| Digital outputs, parameterizable | No | No |
| Short-circuit protection | Yes | No; external fusing necessary, max. 4 A per group, tripping characteristic type B or C |
|
● Response threshold, typ.
|
1 A | |
| Limitation of inductive shutdown voltage to | L+ (-53 V) | L+ (-53 V) |
| Controlling a digital input | Yes | Yes |
| Switching capacity of the outputs | ||
|
● with resistive load, max.
|
0.5 A | 0.3 A |
|
● on lamp load, max.
|
5 W | 5 W |
| Load resistance range | ||
|
● lower limit
|
48 Ω | 80 Ω |
|
● upper limit
|
12 kΩ | 10 kΩ |
| Output voltage | ||
|
● for signal “1”, min.
|
L+ (-0.8 V) | M+ (0.5 V) |
| Output current | ||
|
● for signal “1” rated value
|
0.5 A | 0.3 A |
|
● for signal “1” permissible range, max.
|
0.5 A | 0.3 A |
|
● for signal “0” residual current, max.
|
0.5 mA | 0.5 mA |
| Output delay with resistive load | ||
|
● “0” to “1”, max.
|
100 µs | 100 µs |
|
● “1” to “0”, max.
|
500 µs | 500 µs |
| Parallel switching of two outputs | ||
|
● for logic links
|
Yes | Yes |
|
● for uprating
|
No | No |
|
● for redundant control of a load
|
Yes | Yes |
| Switching frequency | ||
|
● with resistive load, max.
|
100 Hz | 100 Hz |
|
● with inductive load, max.
|
0.5 Hz | 0.5 Hz; According to IEC 60947-5-1, DC-13 |
|
● on lamp load, max.
|
10 Hz | 10 Hz |
