| Article number | 6ES7534-7QE00-0AB0 |
| S7-1500, AI 4x U/I/RTD/TC/AQ 2x U/I ST | |
| General information | |
| Product type designation | AI 4xU/I/RTD/TC /AQ 2xU/I ST |
| HW functional status | FS01 |
| Firmware version | V1.0.0 |
|
● FW update possible
|
Yes |
| Product function | |
|
● I&M data
|
Yes; I&M0 to I&M3 |
|
● Isochronous mode
|
No |
|
● Prioritized startup
|
No |
|
● Measuring range scalable
|
No |
|
● Scalable measured values
|
No |
|
● Adjustment of measuring range
|
No |
|
● Output range scalable
|
No |
| Engineering with | |
|
● STEP 7 TIA Portal configurable/integrated from version
|
V13 / V13.0.2 |
|
● STEP 7 configurable/integrated from version
|
V5.5 SP3 / – |
|
● PROFIBUS from GSD version/GSD revision
|
V1.0 / V5.1 |
|
● PROFINET from GSD version/GSD revision
|
V2.3 / – |
| Operating mode | |
|
● Oversampling
|
No |
|
● MSI
|
Yes |
|
● MSO
|
Yes |
| CiR – Configuration in RUN | |
| Reparameterization possible in RUN | Yes |
| Calibration possible in RUN | Yes |
| Supply voltage | |
| Type of supply voltage | DC |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
| Input current | |
| Current consumption, max. | 200 mA; with 24 V DC supply |
| Encoder supply | |
| 24 V encoder supply | |
|
● Short-circuit protection
|
Yes |
|
● Output current, max.
|
20 mA; Max. 47 mA per channel for a duration < 10 s |
| Power | |
| Power available from the backplane bus | 0.7 W |
| Power loss | |
| Power loss, typ. | 3.3 W |
| Analog inputs | |
| Number of analog inputs | 4 |
|
● For current measurement
|
4 |
|
● For voltage measurement
|
4 |
|
● For resistance/resistance thermometer measurement
|
2 |
|
● For thermocouple measurement
|
4 |
| permissible input voltage for voltage input (destruction limit), max. | 28.8 V |
| permissible input current for current input (destruction limit), max. | 40 mA |
| Constant measurement current for resistance-type transmitter, typ. | 150 Ohm, 300 Ohm, 600 Ohm, Pt100, Pt200, Ni100: 1.25 mA; 6 000 Ohm, Pt500, Pt1000, Ni1000, LG-Ni1000: 0.625 mA; PTC: 0.472 mA |
| Technical unit for temperature measurement adjustable | Yes; °C/°F/K |
| Analog input with oversampling | No |
| Standardization of measured values | No |
| Input ranges (rated values), voltages | |
|
● 0 to +5 V
|
No |
|
● 0 to +10 V
|
No |
|
● 1 V to 5 V
|
Yes |
|
— Input resistance (1 V to 5 V)
|
100 kΩ |
|
● -1 V to +1 V
|
Yes |
|
— Input resistance (-1 V to +1 V)
|
10 MΩ |
|
● -10 V to +10 V
|
Yes |
|
— Input resistance (-10 V to +10 V)
|
100 kΩ |
|
● -2.5 V to +2.5 V
|
Yes |
|
— Input resistance (-2.5 V to +2.5 V)
|
10 MΩ |
|
● -25 mV to +25 mV
|
No |
|
● -250 mV to +250 mV
|
Yes |
|
— Input resistance (-250 mV to +250 mV)
|
10 MΩ |
|
● -5 V to +5 V
|
Yes |
|
— Input resistance (-5 V to +5 V)
|
100 kΩ |
|
● -50 mV to +50 mV
|
Yes |
|
— Input resistance (-50 mV to +50 mV)
|
10 MΩ |
|
● -500 mV to +500 mV
|
Yes |
|
— Input resistance (-500 mV to +500 mV)
|
10 MΩ |
|
● -80 mV to +80 mV
|
Yes |
|
— Input resistance (-80 mV to +80 mV)
|
10 MΩ |
| Input ranges (rated values), currents | |
|
● 0 to 20 mA
|
Yes |
|
— Input resistance (0 to 20 mA)
|
25 Ω; Plus approx. 42 ohms for overvoltage protection by PTC |
|
● -20 mA to +20 mA
|
Yes |
|
— Input resistance (-20 mA to +20 mA)
|
25 Ω; Plus approx. 42 ohms for overvoltage protection by PTC |
|
● 4 mA to 20 mA
|
Yes |
|
— Input resistance (4 mA to 20 mA)
|
25 Ω; Plus approx. 42 ohms for overvoltage protection by PTC |
