| Display |
4.3” TFT LCD |
| Resolution |
480 x 272 |
| Brightness (cd/m2) |
400 |
| Contrast Ratio |
500:1 |
| Backlight Type |
LED |
| Backlight Life Time |
>30,000 hrs. |
| Colors |
16.7M |
| LCD Viewing Angle (T/B/L/R) |
50/70/70/70 |
| Type |
4-wire Resistive Type |
| Accuracy |
Active Area Length(X)±2%, Width(Y)±2% |
| Flash |
128 MB |
| RAM |
128 MB |
| Processor |
32 Bits RISC Cortex-A8 600MHz |
| USB Host |
USB 2.0 x 1 |
| USB Client |
N/A |
| Ethernet |
10/100 Base-T x 1 |
| COM Port |
COM1 RS-232/RS-485 2W/4W COM3 RS-485 2W |
| RS-485 Dual Isolation |
N/A |
| RTC |
Built-in (CR2032 3V lithium battery.) |
| Input Power |
10.5~28VDC |
| Power Consumption |
800mA@12VDC ; 400mA@24VDC |
| Power Isolation |
Built-in |
| Voltage Resistance |
500VAC (1 min.) |
| Isolation Resistance |
Exceed 50MΩ at 500VDC |
| Vibration Endurance |
10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating |
N/A |
| Enclosure |
Plastic |
| Dimensions WxHxD |
128 x 102 x 32 mm |
| Panel Cutout |
119 x 93 mm |
| Weight |
Approx. 0.25 kg |
| Mount |
Panel mount |
| Protection Structure |
NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature |
-20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature |
0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity |
10~90% (non-condensing) |
| CE |
CE marked |
| Software |
EasyBuilder Pro |
