| Type | HFE80V-100 | |
| Coil voltage form | DC | |
| Coil voltage | 12, 24 | |
| Contact arrangement | 1 Form A | |
| Contact version | double contact | |
| Terminal type | Bolt terminal Female | |
| Mounting | Vertical Installation, Horizontal Installation | |
| Coil power | 5W | |
| Sort | Single coil | |
| Contact capacity | AgCuO | |
| Rated voltage(V) | 150Vd.c., 200Vd.c. | |
| Coil angel form | Connector | |
| Shell structure | Standard form | |
| Base structure | Standard form | |
| Coil power | 5 | |
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000Va.c (1min) | |
| Operate time（ms） | ≤30 | |
| Release time（ms） | ≤30 | |
| Coil resistance（Ω） | 28.8×(1±7%) 115.2×(1±7%) |
|
| Creepage Distance（mm） | 14.2 | |
| Electrical Distance（mm） | 7.8 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching voltage（DC） | 200 | |
| Max. switching voltage（VDC） | 250 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 88 | |
| Width(mm) | 47.4 | |
| Heigh(mm) | 82.9 | |
| Mechanical endurance min | 200000 | |
| Electrial eddurance min | 1000 | |
| Contact gap | 1.6 | |
| Product Description | HVDC relay | |
| Application | New energy vehicles | |
| Typical application | New energy vehicles | |
| Weight（g） | about 360 | |
| Volume（mm3） | 345792.48 |
